Professional Video Cameras

Canon XF605

A versatile broadcast quality 4K camcorder, offering advanced AF, connectivity and streaming for demanding productions.

Specifications

  • 1.0-Type CMOS sensor

    Stunning image quality

  • 4K 60P/50P 4:2:2 10-bit and FHD 120P

    High bit depth

  • Wide-angle 15x optical zoom

    L-Series lens

  • Dual Pixel CMOS AF

    Eye Detection AF and intelligent head tracking

  • Canon Log 3 and HDR

    Dynamic range capability

  • Professional I/O connectivity

    Wi-Fi, Ethernet, 12G-SDI and USB-C

Introducing

Canon XF605

Discover the advanced features and functionality that make the XF605 the perfect broadcast video camera for solo shooters.
Canon Camera

Broadcast-quality video

The large 1.0-inch Type CMOS sensor and DIGIC DV7 processor work in harmony to deliver 4K UHD 60P/50P in 4:2:2 10-bit XF-AVC and MP4, as well as FHD 120P HFR for exceptional image quality and flexibility in post-production.

Professional optics and control

Resolve fine details with the 4K ready L-Series lens offering 15x optical zoom, and equipped with independent rings for Zoom, Focus and Iris control. Also featured are three Image Stabilisation modes, as well as built-in ND filters and Infrared mode, offering even greater control.

Canon Camera
Canon Camera

Advanced autofocus

Acquire pin-sharp focus on your subject’s eyes with Eye tracking AF*, and intelligent head tracking via EOS iTR AF X, an innovative ‘deep learning’ technology to track a subject's head, even when looking away.

* Eye Tracking AF also supported in S&F modes.

Professional connectivity and streaming

XF605 seamlessly integrates into live and offline environments, with 12G-SDI, Wi-Fi and Ethernet for IP streaming. The Content Transfer Mobile app enables the editing of News ML-G2 compliant metadata, transferring of footage to your iPhone, and direct uploading to FTP servers.

Canon’s XC Protocol for multi-camera control solutions are also supported.

Canon Camera
Canon Camera

Intuitive controls and customisation

Stay in control and customize the XF605 to your needs with independent controls and 11 assignable buttons. An enhanced touchscreen interface allows for quick and intuitive control of on-screen settings, menu navigation and playback control. A new multi-function accessory shoe opens the door for additional accessories with expanded capabilities.

Recording versatility

Capture an expanded dynamic range in Canon Log 3 for flexibility in post-production or shoot directly in broadcast-ready PQ or HLG HDR formats. Simultaneous recording to dual SD cards in a variety of formats (incl. All-I & Long GOP) offers maximum flexibility for your production needs.

Canon Camera

Content Transfer Mobile App

Content Transfer Mobile is an app for iPhone designed to enable the editing of News ML-G2 standard compliant metadata pre/post capture, as well as the ability to import footage from the camera to the phone, including instant transfer to FTP servers.

Shared colour science

XF605 supports the same colour matrices as Canon's Cinema EOS and EOS R System product ranges, reducing the time needed in post-production to match colour in footage from multiple camera ranges.

Canon Camera
Canon Camera

Durable and lightweight

With its notably compact size and body weight of approximately 2,010g, XF605 is the perfect ‘carry-on’ companion. Despite its small dimensions, it’s a highly capable workhorse camcorder, with a durable dust and drip-proof design.

Sensor Sensor Size

1.0 type (3.2μm)

1.0 type (3.2μm)

1.0 type (3.2μm)

Sensor Effective Pixels

8.29 million (Approx.) (Total Pixels: Approx. 13.20 million)

8.29 million (Approx.) (Total Pixels: Approx. 13.20 million)

8.29 million (Approx.) (Total Pixels: Approx. 13.20 million)

Lens Magnification, Focal Length, Aperture

Optical 15x 25.5 - 382.5 mm F/2.8 - 4.5

Optical 15x 25.5 - 382.5 mm F/2.8 - 4.5

Optical 15x 25.5 - 382.5 mm F/2.8 - 4.5

Lens ND Filter

3 - Density (ND 1/4, ND 1/16, and ND 1/64)

3 - Density (ND 1/4, ND 1/16, and ND 1/64)

3 - Density (ND 1/4, ND 1/16, and ND 1/64)

Lens Image Stabilization

Optical (Powered IS / Dynamic Mode)

Optical (Powered IS / Dynamic Mode)

Optical (Powered IS / Dynamic Mode)

Lens Control Rings

3 (Focus / Zoom / Iris)

3 (Focus / Zoom / Iris)

1 (Focus / Zoom Switchable)

Imaging Engine

DIGIC DV7

DIGIC DV6

DIGIC DV6

Auto Focus

Dual Pixel CMOS AF

Eye Detection AF

EOS iTR AF X

Face Priority AF

Face Only AF

Tracking AF

Dual Pixel CMOS AF

Face Priority

Face Only AF

Dual Pixel CMOS AF

Face Priority

Face Only AF

Infrared Compatibility

YES

YES

YES

LCD Monitor

3.5-inch

Approx. 2.76 million dots

Capacitive Touch Panel

3.5-inch

Approx. 2.76 million dots

Capacitive Touch Panel

3.5-inch

Approx. 1.56 million dots

Capacitive Touch Panel

EVF

0.36-inch

(Approx. 1.77 Million Dots)

0.36-inch

(Approx. 1.77 Million Dots)

0.24-inch

(Approx. 1.56 Million Dots)

Media Memory Card

x2 SD Card

(UHS-II Compatible)

x2 SD Card

(UHS-I Compatible)

x2 SD Card

(UHS-I Compatible)

Connectivity SDI

x1 (12G-SDI)

x1 (12G-SDI)

x1 (3G-SDI)

Connectivity XLR

x2

x2

x2

Connectivity HDMI

x1 (Type-A)

x1 (Type-A)

x1 (Type-C)

Connectivity USB

x1 Type-A (Host)

x1 Type-C (Device)

x1 (Mini-B)

x1 (Mini-B)

Other Terminals

BNC x2 / Headphone / Mic / Remote A, B / DC

BNC x2 / Headphone / Mic / Remote A, B / DC

Headphone / Mic / Remote A / DC

Wi-Fi

2.4GHz/5GHz

11a/b/g/n/ac MIMO

2.4GHz/5GHz

11a/b/g/n

2.4GHz/5GHz

11a/b/g/n

Ethernet (Wired LAN)

YES

YES

YES

Accessory Shoe

Cold Shoe +

Multi-Function Shoe

Cold Shoe

Cold Shoe

Included Battery

BP-A30

BP-A30

BP-828

Included Power Adapter

CA-CP200L

CA-CP200L

CA-946

Included Charger

CG-A20

CG-A20

CG-800

SIGN UP NOW

Register your interest in the Canon XF605

Be the first to receive the latest updates on the Canon XF605, offers from Canon, tips and tutorials, latest news, and invites to local events.

What’s In The Box?

  • XF605 Camera Body

  • Lens Hood

  • Eye cup

  • Battery Pack BP-A30

  • Charger CG-A20

  • Compact Power Adapter CA-CP200 L

  • Mic Holder

DOWNLOAD THE NEW FIRMWARE NOW

To take advantage of the new Firmware, where you will to be taken to the Canon Download page.

Compatible Accessories

  • Canon Camera

    Battery Pack BP-A30 (included) / BP-A60

    The BP-A30 (3100mAh) and high capacity BP-A60 (6200mAh) are dedicated Li-ion battery packs for compatible Canon cameras.
  • Canon Camera

    Battery Charger CG-A10

    The CG-A10 is a dual battery charger for BP-A30 and BP-A60 Li-ion batteries.
  • Canon Camera

    Battery Charger CG-A20 (included)

    The CG-A20 is a single battery charger for BP-A30 and BP-A60 Li-ion batteries.
  • Canon Camera

    GPS Receiver GP-E2

    The GP-E2 unit offers GPS tagging and logging abilities help you to locate exactly where your images were taken.
  • Canon Camera

    Remote Controller RC-V100

    Wired remote control of your camera enables control over virtually all camera functions.
  • Canon Camera

    RC-IP100 remote camera controller

    A high quality controller with a multi-function joystick and intuitive touchscreen for easy control of up to 100 connected cameras.
  • Canon Camera

    Wide Attachment WA-U58

    This wide attachment extends the cameras optical capability by 0.8x enabling better capture of very wide scenes or shooting in confined spaces.
  • Canon Camera

    Tele-converter TL-U58

    This tele-converter extends the cameras optical capability by 1.5x to bring distant subjects even closer.
