Canon CR-N300 PTZ Camera

PTZ Cameras

Canon CR-N300

Equipped with 4K UHD resolution, a 20x optical zoom, Hybrid Auto Focus, numerous IP streaming and control protocols, you can engage your audience in new ways.

CLOSE THE DISTANCE WITH UNRIVALLED CLARITY

The CR-N300 makes content creation and streaming simple. Equipped with a 1/2.3-inch CMOS sensor with 4K UHD resolution, 20x image stabilised optical zoom and a wide range of streaming and control protocols, it’s the ideal choice for a variety of productions.

See full specification

cr-n300_gallery_01

cr-n300_gallery_02

cr-n300_gallery_03

cr-n300_gallery_04

cr-n300_gallery_05

cr-n300_gallery_06

cr-n300_gallery_07

cr-n300_gallery_08

cr-n300_gallery_09

cr-n300_gallery_10

4K UHD

1/2.3-type CMOS sensor for stunning quality
20x Optical Zoom

From wide-angle to telephoto
DIGIC DV6 Processor

Guarantees great results in all situations
Support for a wide range of control and streaming protocols

RTMP/RTMPS, NDI|HX*, RTP/RTSP, SRT, FreeD and Canon’s XC Protocol

* NDI is a trademark or registered trademark of NewTek Inc. in the United States and other countries
Hybrid AF

For fast and accurate focusing even in low light
Optical Image Stabilizer

Exceptional stability for smooth PTZ operation

See full specification Get Support

Auto Tracking

Auto Tracking Application RA-AT001. Unlock the potential to track the main speaker with face detection as they move around the stage, automatically. Optimise production efficiency for lectures, corporate events, houses of worship, live performances and broadcast.

Find out more

RESOLUTION

Razor Sharp 4K Imagery
OPTICAL ZOOM LENS

20x Optical Zoom
STREAMING AND CONTROL PROTOCOLS

IP Streaming and Control
AUTOFOCUS

Hybrid AF
CONNECTIVITY

Flexible connectivity and workflow
PAN AND TILT

Smooth precise pan and tilt

Quick Comparison

Canon CR-N500 PTZ Camera

CR-N500

CR-N300

CR-X500

CR-X300

Sensor Size

1 Inch-Type CMOS Sensor

1/2.3 Inch-Type CMOS Sensor

1 Inch-Type CMOS Sensor

1/2.3 Inch-Type CMOS Sensor

Optical zoom

15x Optical Zoom

20x Optical Zoom

15x Optical Zoom (30x Advanced)^(1)*

20x optical zoom

Focussing System

Dual Pixel CMOS Auto Focus

Hybrid Auto Focus

Dual Pixel CMOS Auto Focus

Hybrid Auto Focus

Maximum resolution output

4K UHD 30p

4K UHD 30p

4K UHD 60p

4K UHD 30p

Indoor/Outdoor

Indoor

Indoor

Outdoor (IP55 Water and Dust Resistant)

Outdoor (IP65 Water and Dust Resistant)

All data is based on Canon standard testing methods except where indicated. Subject to change without notice.

* 30x advanced zoom in FHD

Razor sharp 4K imagery

A 1/2.3-type CMOS Sensor and DIGIC DV6 processor combine to deliver exceptional 4K UHD imagery (up to 30p), or outstanding Full HD footage thanks to over sampled HD processing. These technologies provide an image quality with superior levels of detail fit for any production.

20x Optical zoom for incredible flexibility

Capture all the detail you need, thanks to Canon’s advanced 4K optics which feature a flexible 20x optical zoom covering a broad focal range of 29.3-601mm (35mm equivalent), ensuring great flexibility. Equipped with image stabilisation, for minimal image disruption when moving.

IP Streaming and Control to transform your productions

The CR-N300 boasts a comprehensive range of IP control and streaming protocols up to 4K UHD 30p allowing for greater control for your production needs. Featuring major protocols such as NDI|HX*, RTMP, RTP/RTSP, RTMPS, SRT, FreeD and Canon’s XC Protocol, it will fit into most new or most existing systems, making it an extremely flexible option.

*NDI is a trademark or registered trademark of NewTek, Inc. in the United States and other countries

IP Streaming and Control to transform your productions

Hybrid AF for precise focus

The CR-N300 combines high-precision contrast AF with high-speed phase-detection AF, ensuring rapid and accurate focusing of the subject, even in low light conditions.

Equipped with a bespoke external sensor which measures the distance to the subject and compares the point of focus with that determined by the Contrast AF system. This Hybrid AF system is particularly effective in low light situations and provides fast, accurate and reliable Autofocus with greater accuracy than Contrast AF alone.

Flexible connectivity for your workflow

The CR-N300 features a whole host of connections to ensure the ultimate flexibility in workflows. Featuring a HDMI port which can achieve 4K UHD, 4:2:2 10-bit. The camera also boasts a 3G-SDI port, USB Port, 3.5mm Audio Input and a PoE+ LAN port.

Flexible Connectivity

Smooth, precise control

The CR-N300 is equipped with a high-precision drive mechanism, enabling the Pan and Tilt movement to be finely adjusted at variable speeds using controllers such as RC-IP100, Canon Remote Camera Control Application or a tablet via Wi-Fi, to capture the perfect shot.

Image Presets for Quick and Easy Use

The CR-N300 is equipped with multiple Image Presets that allow for quick and easy adjustments of video settings for specific environments. The user can also register up to 100 preset positions on the CR-N300 making productions simple and easy.

Controller Smooth and precise control

Small and compact for easy installation

The CR-N300 is small and discreet at 154 x 178 x 164 mm (W x H x D), and weighs just 2.2kg making it ideal to be installed in environments where space is at a premium.

Small and compact for easy installation

Seamless High Quality 4K Video Streaming

With the free of charge* Webcam Driver**, you can enjoy seamless video streaming in up to 4K 30p with maximum 5 selected Canon PTZ Cameras*** via a simple ethernet connection. Compatible with most conferencing platforms and applications which require UVC, this Windows OS software is a virtual USB driver which allows an easy video streaming integration, ideal for video conferencing and online lectures.

* A third party license may be required
** Software available in June 2022
*** Applicable only to the CR-N500, CR-N300 and CR-X300

What's in the box

CR-N300 Camera
Ceiling Plate (with fittings)
Safety Wire
Camera-to-mount Safety Wire
AC Adapter
Remote Control (WL-N01)
Batteries

Register your extended year warranty

Buy any of our selected Remote PTZ Cameras or Controllers and you can enjoy greater peace of mind with our additional 1 Year Warranty coverage

Canon CR-N300
Ratings & Reviews

Canon CR-N500 PTZ Camera

CR-N500

With a 15x optical zoom and 4K UHD shooting capabilities, the CR-N500 offers precise control and seamless IP streaming, even in low light conditions
• Powerful 4K Imagery
• Stabilised 15x Optical Zoom
• IP Streaming and Control to transform your productions

Remote Camera Control Application

Canon Remote Camera Control Application

Complete your PTZ infrastructure with this free Canon software that enables control of up to 20 Canon PTZ cameras, nine of which can be shown as a live preview at any one time on the user interface.
• Remote control from your PC
• Monitor and view settings instantly
• Full control over pre-set positions

RC-IP100

Pan, tilt and zoom effortlessly with this high-quality controller featuring a multi-function joystick and intuitive touchscreen for easy control of up to 100 cameras over IP.
• Control up to 100 cameras remotely
• Manage up to 100 stored positions
• Assign and refine with custom controls

CR-X500

With a robust and weatherproof housing plus 4K UHD resolution, 15x optical zoom, 12G-SDI and Dual Pixel CMOS AF, the CR-X500 is the ideal PTZ camera for remote productions and monitoring.
• 4K UHD Resolution
• 15x Optical Zoom
• Weatherproof housing IP55 Dust proof and waterproof rating
